📌Features
.Standalone or PC on line through the software
.Support 10,000 history transaction
.Card capacity is 10,000 cards
.Built-in RS-232/RS-485 interface
.Built-in TCP/IP for Intranet or Internet network (Option device)
.Built-in Watch Dog feature
.8 Programmable time zones, 3 schedules per time zone
.Built-in clock and calendar
.Control 2 Long Range Reader to control Vehicle entry and Exit
.Data is protected even after power failure
.Provides two DI point for Vehicle proximity Coil or Infrared device,
.Provides three Relay output
.With Anti-Pass Back feature
📌Specifications
|
Specification
|
|
Keypad：
|
4 x 4 16 Keys Touch Keypad (Blue Backlight LED)
|
|
Power：
|
AC 110VAC ~ AC 220VAC
|
|
LCD：
|
160 x 80 Dot (Blue Backlight LCD)
|
|
Dimension：
|
290(L) x 240(W) x 78(H)mm
|
|
Relay：
|
4 Relay Contact (Max. DC 12V 1A)
|
|
Communication Interface：
|
Provides 2 * RS232, 1 * RS485 or TCP/IP module (option device)
|
|
working environment ：
|
Humidity：20% - 90%
|
|
Operating Temperature：0°C～50°C
|
📌Ordering Information
JST-520 R － RS-485
JST-520 T － TCP/IP
📌Reference models
| Model |
Picture |
Product Name |
| JLR-902 |
 |
Integrated UHF Reader |
| JLR-903 |
 |
Mid-distance UHF Integrated Reader |
